Product Highlights:
 |
Sunlight Readable |
|
PIP |
|
IP65 Proof |
|
24V DC Input |
|
Optional: Elo SAW TouchScreen |
|
|
|
23.1" Marine Bridge System Display, Panel Mount IP65 aluminum housing with powder coating design (IP54 rear), 1600x1200, 250nits. (Model: WPM-MAR-2300S1-S2)
Features |
• Ease of use front panel 5 key OSD control
• Transflective film technology enhance visibility
• Panel (flush) mount IP65 aluminum housing with powder coating design (IP54 rear)
• 9 ~ 36V DC power input acceptable(90 to 265 V AC (for option)
• High quality touchscreen for option
• 3mm Anti-reflective protection glass
• PIP(picture in picture) function and multi-video inputs
|
 |
|
Specs:
• Pixel Number : Pixel Number
• Pixel Pitch(R&B) : 0.294 (H) x 0.294 (V)
• Contrast Ratio : 500:1 (typ.)
• Light Intensity : 250 (typ.)
• Viewable Angle : -85~85 (H); -85~85 (V)
• Active Display Area : 470.4 (H) × 352.8 (V)
• Max Colors : 16.7M (8bits/color)
more...
|
|
